36V 29Ah 1kWh Bike Rear Rack Bag Battery

3,987 views · Published 2 November 2018 · 3:19 · Indexed 28 September 2026

Channel: Damian Rene · 2018 · Science & Technology

Watch on YouTube

*WARNING: Just a single 18650 cell has the potential to start a fire in your home / workplace. Building a battery is a very dangerous task that should only be done by an expert in electricity and electronics.*
---------------------------------------------------------------------------------------------------

This 36V 29Ah Li-ion battery made with 18650 Panasonic NCR18650PF cells. These powerful cells are very round for any electric vehicle battery application: high energy density, power, life span and cycling life.

This is one of my most beloved standalone battery designs as it shows clearly all different kinds of utility a battery can be made with as very high energy available (range in an EV.), high power, USB charging port, auxiliary ports, space to keep other things, rear position light, etc.

It is designed and built inside a special high quality bag what helps to have is fast installed and to carry it easily.

It has a raw maximum discharge current of 100A continuously (3kW) and 200A peaks (6kW) although for its use (a 600W electric bike) it is just paired enough with a 30A continuous limit BMS.

Basic specifications are:
- 10s10p 36V 29Ah 18650 Panasonic NCR18650 PF cells
- Dimensions (max): 190mm x 180mm x 70mm
- Weight: 5Kg // Volume: 2.4L
- energy density: ~540Wh/L
- specific energy: ~215Wh/Kg.
