Off Screen Triggers? - How to Read an Oscilloscope Datasheet 3/3

1,236 views · Published 13 November 2018 · 12:44 · Indexed 10 October 2026

Channel: Keysight Labs · 2018 · Science & Technology

Watch on YouTube

Sampling, triggers, & memory

Click to subscribe! ► http://bit.ly/Scopes_Sub ◄

Full playlist: https://www.youtube.com/playlist?list=PLzHyxysSubUmKkWaxbCbv8ptpXxgel1IE

Questions/comments? Ask me on Twitter:
@DanielBogdanoff https://twitter.com/DanielBogdanoff

Learn more about using oscilloscopes:
http://oscilloscopelearningcenter.com

Check out the EEs Talk Tech podcast:
https://www.youtube.com/playlist?list=PLzHyxysSubUnAMeCIi2-S0Vm7YtSAGqx_

Topics & time tags:

Oscilloscope acquisition system:

Interleaving of ADC channels and oscilloscope memory depth to streamline the architecture mode.

2:00
Acquisition modes:
Normal, peak detect, high resolution, averaging

2:15
oscilloscope segmented memory

2:30
Roll mode - should it auto-switch or not. Daniel hates auto-roll mode

3:15
An oscilloscope triggering system isn't as straightforward as you might expect.
Trigger holdoff
External trigger in
Oscilloscope trigger sensitivity

5:00
Types of oscilloscope triggers

5:30
Cursors aren't warranted, there's an accuracy associated with them

Measurements are listed and measurement logging.

6:10
Burying BenchVue on page 32 of the data sheet.

7:00
Waveform math + search and navigate on oscilloscope

8:30 Oscilloscope safety and environmental specs and certifications.

10:00 What comes standard with an oscilloscope?

10:30 Bonus literature and oscilloscope hardware and software upgrades.
