Armasight Spark Core - Night Vision Unboxing Basic Overview

4,583 views · Published 16 January 2015 · 6:46 · Indexed 10 October 2026

Channel: The Heresy Group · 2015 · Sports

Watch on YouTube

DESCRIPTION

For years, development and improvement of consumer-orientated single stage Gen 1 technology has stood still – until now. Traditionally, Gen 1 tubes are made of glass – making them quite fragile and easily damaged, and have relatively low resolution, with very evident image edge distortion.

Introducing an Armasight exclusive – CORE (Ceramic Optical Ruggedized Engine) technology image intensiffier tubes! While CORE does not contain a micro channel plate (and so by definition lands in the Gen 1 category) that is where the parallels end. Instead of glass, CORE tubes use a specially formulated ceramic compound fused with metal alloys similar to those used in production of Gen 2 and Gen 3 image intensiffier tubes.

Further advances in CORE have almost removed edge distortion, dramatically increased photo-sensitivity and most importantly, almost doubled resolution up to 70 lp/mm! The Armasight Spark is the perfect partner for this new hybrid tube-type – a rugged, but light-weight multi-purpose night vision monocular. With optional accessories, it can be used hand-held or head-mounted; with a day scope adapter, it can convert your existing day scope to night vision at a budget price. With optional 3X a-focal lens and IR illuminator, it can serve as a medium range, ultra-high resolution spotting scope and with optional camcorder/camera adapter, you can even take footage or stills though it in  darkness.

The Armasight Spark is the ideal night vision unit for the outdoorsman or first responder who demands more resolution, image clarity and durability than standard Gen 1 can offer.

ARMASIGHT SPARK: RULING THE NIGHT ON A BUDGET Review by Aaron Fouraker (click to see more)

Customers Reviews on amazon.com (click to see more)

Reviews on forum.snipershide.com (click to see more)


FEATURES

Compact, rugged design
Waterproof
Head mountable for hands-free usage
Ergonomic, simple, easy to operate controls
Utilizes single CR123A lithium battery
Adaptable for use with cameras
Built-in Infrared illuminator
Limited two-year warranty
SPECIFICATION

Resolution 60-70 lp/mm
Magnification 1x, optional 3x
Multi-Purpose System Yes
Exit Pupil Diameter, mm 8
Eye Relief, mm 20
Lens System F1.7, 35mm
FOV 30°
Range of Focus 0.25 to infinity
Diopter Adjustment +5 to -5 dpt
Controls Direct
Infrared Illuminator Yes (built in with flood lens)
IR Indicator Yes
Power Supply CR-123 Lithium 3V (1) or CR123 type rechargeable batteries with voltage 3.2V (1)
Battery Life 40 hrs
Environmental Rating Waterproof and weatherproof
Operating Temperature -40 to +50 °C
Storage Temperature -50 to +60 °C
Dimensions 159 x 49 x 82 mm / 6.3 x 1.9 x 3.2 in
Weight 0.37 kg / 0.8 lbs
Warranty 2 Years
