Arduino 2 Heater Energy Balance Verification
3,358 views · Published 2 February 2018 · 16:29 · Indexed 20 September 2026
Channel: APMonitor.com · 2018 · Science & Technology
We derive a nonlinear transient model for two heaters and compare the model predictions with the Arduino temperature control lab measurements. A next step in the modeling, beyond the single heater model, is to develop a dual heater model and add the heat transfer between them. Code is available in MATLAB, Simulink, and Python to validate the energy balance model. See http://apmonitor.com/pdc/index.php/Main/ArduinoModeling2 for source code or https://apmonitor.com/heat.htm for TCLab overview.
