PT namePlate details Explanation and What is PT Voltage factor in tamil
4,378 views · Published 1 May 2018 · 8:56 · Indexed 20 September 2026
Channel: Tech Doct · 2018 · Education
Free Electrical Calculator for android Best android app for Electrical Engineer and EEE student
In this, We have fully explained voltage factor of the PT and PT nameplate details in Micro levels....
Defining the transformer ratio Up/Us
• Preferably select as primary voltage the nominal service voltage of the network.
• Select as secondary voltage the nominal input voltage of the equipment to be fed.
Defining the accuracy class against the application
Standard reference = Class 0,1 or 0,2
Tariff metering = Class 0,5 or 0,2
Divisional industrial metering = Class 1
Measure display = Class 1 or 3
Protection = Class 3P or 6P
Defining the voltage factor
• The voltage factor is determined by the maximum operating voltage, which depends on the neutral system and the voltage transformer primary winding earthing conditions.
• When the voltage transformer is connected between two phases, the voltage factor is 1.2Un continuous.
• When the voltage transformer is connected between phase and earth, the voltage factor depends on the neutral system:
- 1.9 Un for 30 s, in a non-effectively earthed neutral system with automatic earth-fault tripping.
- 1.9 Un for 8 h, in an isolated neutral system, or in a resonant earthed system, without earth-fault tripping. #relay, #protection, #electrical in tamil, #transformer protection, #generator protection
