3-gear coupling 1
2,810 views · Published 21 February 2012 · 0:14 · Indexed 29 September 2026
Channel: thang010146 · 2012 · Science & Technology
There is no bearing for the internal gear. Z1 = Z2 = 20 Z3 = 30 Z1, Z2 are tooth numbers of the external gears. Z3 is tooth number of the internal gear. The external gears have the same velocity and rotation direction. Velocity can be altered if Z1 differs from Z2 STEP files of this video: https://www.mediafire.com/file/b8idqwrrycytnxi/3gearCoupling1STEP.zip/file Inventor files of this video: https://www.mediafire.com/file/gejecr6vcilr7al/3gearCoupling1Inv.zip/file
