Removing the Inductive Shunt to Test the Ainslie Measurement
227 views · Published 29 August 2009 · 4:05 · Indexed 14 November 2026
Channel: Aaron Murakami · 2009 · Science & Technology
The 1 ohm inductive shunt is removed from the Rosemary Ainslie circuit and a calibrated non-inductive 0.25 ohm current-sensing resistor put back in its place, specifically to remove the objection that shunt inductance was producing the result. The battery reads 12.73 V and the Fluke shows 2.7 mV RMS at roughly plus and minus 20 to 50 mV. The waveform keeps the same shape, slightly smoother, with less magnification of small tuning changes. Chapters 0:00 Why the inductive shunt came out 1:50 The calibrated 0.25 ohm resistor 3:18 Same waveform on the new shunt https://emediapress.com https://emediapress.com/energytimes Rosemary Ainslie COP 17 circuit, 2009 bench footage. Posted 2009-08-29.
